—The ultimate solution for smoke and carbon monoxide alarm systems for data centers (NFPA 72 / UL 268 / UL 2034)
In engineering projects, product managers care about not just “whether it can detect fires,” but rather the overall reliability, integrability, and compliance of the system. Purchasing managers focus on the cost (equipment, installation, and subsequent maintenance), risk(certifications), and supply stability (capacity and delivery time) in data center projects. Ultimately, data center operators are interested in the system stable 24/7 operation with zero interruptions, low false alarms, and rapid response.
You’re not choosing the number of alarms but designing a system that can detect risks early and respond automatically. The article introduces an excellent system solution that meets the requirements of a low false-alarm rate, timely response, and system scalability, while minimizing interference with daily operations and manual maintenance costs.
Why Smoke & CO Alarm Design Fails in Data Centers
In Token Data Center (Blockchain Data Center/IDC) projects, how many smoke detectors and CO detectors need to be installed? Why do many projects not “under-install,” but “install the wrong ones”?
In actual data center projects, we frequently encounter the following situations:
Leading to Results:
NFPA72 Coverage vs Real Data Center Conditions
- NFPA 72 smoke detector spacing is typically approximately 84㎡ (900 ft²) per detector. However, in data centers, due to airflow effects:
- The actual effective coverage area may decrease by 30%–50%.
- In data center fires:
- Approximately 60% are due to early electrical overheating or cable burning.
- These stages often involve the initial release of CO, followed by visible smoke.
- Relying solely on smoke detectors will result in “too late detection.”
- According to operational data:
Approximately 40% of false alarms in data centers are related to data center airflow/environmental interference.
Reasons include:
Why install Wrong Smoke and CO Alarms in a Token Factory?
1. Misconception: Treating data centers like ordinary buildings
Many projects directly apply:
- Office smoke detector placement
- Residential CO alarm logic
But the data center environment is completely different:
- High airflow
- High-density equipment
- Long-term operation
2. The differences between smoke detectors and carbon monoxide detectors were not fully considered.
3. Alarm system not linked with control system
Missing:
- Fan control
- Power failure control
- Electrical control equipment
- Central control panel system
- Alarm ≠ Safety response
Airflow Impact: Cold Aisle vs Hot Aisle
Ignoring airflow organization (hot aisle/cold aisle) leads to inaccurate data center airflow fire detection.
- Cold aisle airflow will:
- Dilute smoke
- Delay smoke detector triggering
- CO electrolyte freezing
- Cause cold aisle smoke detection delay
- Hot aisle airflow will:
- CO electrolyte drying and inactivation
- CO dilution and detection delay
- Smoke sensitivity drift
- Dust and water vapor false alarms
- Cause Shortened lifespan, decreased reliability, and increased maintenance costs in data center.
Why CO Detection Is Critical in Early Fire Stage
60% of data center fires are electrical fires. Ignoring CO as an early warning sign.
In the early stages of an electrical fire:
However, most solutions:
Configuring a certain number of carbon monoxide detectors can detect fires on time, avoiding the losses caused by the delayed alarm of smoke detectors alone.
How to Build a Stable System in a Token Factory? (ODM/OEM Solution）
With over 20 years of ODM/OEM experience, CFS recommends fire alarm system architecture including a central control system + detection modules（smoke detection, carbon monoxide detection） + electronic control system.
Layer 1: Detection Modules
How Smoke Detectors Work (UL268)
Recommended Configuration from UL 268:
Deployment Principles from NFPA 72:
Smoke alarms use photoelectric principles:
- Smoke enters the detection chamber
- Light scattering changes
- Photoelectric sensor detects signal changes
- MCU makes judgment → Triggers alarm
In one word, the principle is Particle detection → Signal change → Judgment logic
How CO Detectors work (UL 2034 / UL 2075)
Why is a CO sensor necessary?
In the early stages of an electrical fire:
👉 CO concentration rises earlier than smoke
Recommended Locations:
Technical Principle of Electrochemical CO Sensor:
Layer 2: Alarm and Central Control Panel Linkage (Core)
The linkage between alarm devices and the fire alarm control panel is essentially a closed-loop control system of “detection-judgment-execution”. When detection modules detect an abnormal signal, detection modules send digital signals to the fire alarm controller (FACP). The controller triggers the corresponding linkage strategy based on preset thresholds and time curves. The whole process needs stable communication protocols (such as RS485/Modbus) and system redundancy to avoid single points of failure to make sure response quickly and reliability. In critical scenarios such as data centers, this linkage is not only used for alarms but also for achieving automated safety response, reducing manual intervention time, and thus improving the overall system’s safety and compliance.
Layer 3: Central Control Panel and electronic control Linkage (Core)
The linkage between the central control panel and various electrical control devices follows a typical “signal-driven + logic-executed” architecture. When receiving a signal from the detection module, the central control panel sends instructions to the electrical control unit via relay outputs or communication interfaces (such as RS485/Modbus).
The system must comply with NFPA 72 requirements:
In general, the whole system runs linkage logic:
CO or smoke detection →Control panel →Electrical Control system:
- Activate alarm
- Send alarm signals to monitoring control panel platform
- The control platform sends commands to the electronic control system
- Shut down air conditioning recirculation
- Activate exhaust system
How to Calculate the Number of Smoke & CO Alarms
Basic Calculation Formula:
How many Smoke Detectors:
Total Area ÷ Coverage Area × Safety Factor
Example 1000㎡ Data Center:
1000 ÷ 60 ≈ 17 smoke detectors
Numbers of Carbon Monoxide Alarms:
CO alarm calculation by Functional Area:
- UPS Area: 2–4 Carbon Monoxide alarms
- Battery Area: 1 Carbon Monoxide Alarm per 50–80㎡
- Server Room: 1 Carbon Monoxide Alarm per 100–180㎡
👉 Overall Recommendations:
Area | Smoke Detector | CO Sensor |
|---|---|---|
Main Server Room | High Density | Medium Density |
Battery Room | Medium Density | High Density |
UPS | Medium Density | High Density |
Why Choose CFS for Data Center Projects
If you are interested in:
CFS has over 20 years of ODM/OEM experience with NFPA72/UL268/EN14604 standards and provides the following support:
Please contact your engineering expert now
Case Study – Data Center Optimization
During the implementation of a data center project in Europe, the initial solution only used point-type smoke detectors. The server room employed a typical cold aisle structure with high air conditioning velocities, causing smoke to be rapidly diluted and deviate from the detection path, resulting in significant detection delays during operation.
Following on-site evaluation and retesting, we engineered and optimized the solution: firstly, we added carbon monoxide (CO) sensors LDCS1511A to the UPS, battery, and critical cable areas to capture gas signals released during the initial stages of electrical overheating; secondly, we re-optimized the density and location of smoke detectors based on airflow organization, and integrated the alarm system into the BMS for hierarchical linkage and centralized monitoring. After the modification, continuous operation verified that the overall system detection lead time improved by approximately 40%, the false alarm rate decreased by approximately 35%, and it successfully passed relevant regulatory review.
This case demonstrates that in data center scenarios, a single smoke detector solution is insufficient to meet actual needs; a comprehensive design integrating “smoke + CO + system linkage” is essential to achieve a stable, reliable, and auditable security system.
Why Trust Our Engineering Team
👉 Contact Our Engineering Team
FAQ
Summary
In data center scenarios:
- Insufficient smoke detectors
- Essential CO detection
- A linked system is mandatory
A truly safe system is not about “how many alarms are installed,” but rather:
Whether a complete detection + judgment + control system has been established.
